POLAR LabelSystem DC-M

POLAR LabelSystem DC-M

Stand-alone die-cutter for high-quality small and medium runs, with manual loading.

POLAR's stand-alone die-cutter DC-M is extremely flexible, easy to operate and provides maximum die-cutting accuracy and a variety of shapes and sizes.

The workflow: First of all the material to be die-cut is cut into label stacks by a high-speed cutter.
The precut label stack is manually deposited in the feeder tray, then automatically moved in front of the stamping punch which presses it through the cutting die (puncture principle). This gives the label its intended shape. A delivery chute takes the die-cut final products to the exact position on the packing table.

Customer benefits:

  • Easy set-up of the cutting die off the machine, thanks to the alternate-frame system.
  • OnePunchRegister permits to adjust the cutting die to the printed image with only one pack.
  • Motorized precision adjustment of the cutting die allows to work at the machine without any tools.
  • Maximum die-cutting precision and high lifts are ensured, because the die-cutting material is aligned on four sides.
  • Large format range

Technical Data
 Label size, min. 20 x 40 mm
Label size, max. 170 x 210 mm
 Die-cut format, min. 16 x 36 mm
 Die-cut format, max. 166 x 206 mm
 Clamp opening, min. 35 mm
 Clamp opening, max. 125 mm
Max. performance per minute 8 to 12 cycles

Components

Fully equipped system with no additional components

Fully equipped system with no additional components
